RhinoRack Stealthbar Kings Awning Adapter v5

This thing was made with Tinkercad. Edit it online https://www.tinkercad.com/things/bXrPMUhk0BG

Rhinorack Stealthbar adapter to hold brackets for Kings Awning.

Bolt holes for captive bolts in track of the roof bars with clearance on top to allow a socket to tighten the nuts.

Curved surface to align with the shape of the roof bars, with a raised section to clear the endplates of the bar supports.

Captive nut cutout to hold the nuts from the Kings bracket to allow the bolts to be tightened from the top.

Print Settings

Printer:

Up Plus

Rafts:

Doesn't Matter

Supports:

Yes

Infill:

Strong

Filament: Tiertime ABS Black
