ATI Radeon X1050 Slot Bracket

A slot bracket for a second-hand ATI Radeon X1050 graphics card that was missing its bracket.

Modified from thing:2860818 by importing the STL into FreeCAD, converting it to solid, then plotting the cutouts. FreeCAD file included.

Print Settings

Printer:

Modded HE3D EI3

Rafts:

No

Supports:

Yes

Resolution:

0.2mm

Infill:

N/A

Filament:

Hatchbox PLA

Black

Notes:

Print with supports to ensure the slot clip is printed properly. Make sure to align the bracket for proper printing.

If the slot clip doesn't align, try loosening the nuts on the DVI connector to allow a bit of bending.

Category: Computer
