Mid and Tall Sizes for Expandable Citadel Paint Tray

Additional heights of the original tray, for those with a bunch of short bottles
In the contest Painting Helpers
14
51
0
387
updated November 3, 2023

Description

PDF

I loved the original (the multi_small_335mm version), but wanted to have some easier access to short Citadel bottles on 2nd/3rd rows.

Be advised: this is a very quick and dirty remix made in a few minutes in 3d builder by kit-bashing together a few instances of the original model, then tossing in negative volumes to clear out excess. The polygons already don't look great in preview, and it ends up with a couple of small unintended gaps, but nothing that's visible when in use.

Supports everywhere (only necessary for the interior rim); no need to remove them post-printing, as they're not noticeable at all.

This is rough enough that I wouldn't post it without refinement, but a couple of people have asked for it from a posted make, and it worked well enough for me that I also haven't been sufficiently motivated to go import and draft it all in OnShape/Fusion yet. If I clean it up, I'll add a revision to the files here.

Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

Two taller models that snap together with the original citadel bottle model height, but which fit behind and enables tiered storage of the short bottles.
