Hero Me Gen 6 Frame Adapter with integrated BL Touch Mount For Voxelab Aquila

Does not contact gantry when homing
2
16
0
384
updated July 9, 2022

Description

PDF

When using the hero me on the Aquila, the provided BL Touch wings contact the gantry when homing. I first printed a custom BL touch wing, but it was slightly fragile. So I integrated the wing into the Aquila adapter bracket (voxelab_aquila_pro-oem-mk8-ms-bms-gantry_adapter.stl).


It's a bit quick and dirty but works well.

Offsets are:
x_offset: -55
y_offset: -19
