Apple TV Stand Plate for easel design TV Stand (e. g. Hama 00118099)

Designed for the following Hama 00118099 easel design TV stand:

https://uk.hama.com/00118099/hama-easel-design-tv-stand-191-cm-75-black

https://www.amazon.de/gp/product/B07XYC6YWQ

Certainly usable or customizable for other stands.

I printed mine with black PLA.

I had to use a right angle HDMI connector on the Apple TV, as the TV stand uses a tube right in the middle of the stand that would collide with a standard cable. I decided to use this solution because otherwise the stand plate would have protruded way too far forward.

Required printed parts:

• 1 x “AppleTV TV-Stand - Plate-Body.stl”
• 2 x “AppleTV TV-Stand - Hook-Body.stl”

Required metal parts:

• 4 x M4 x 20 mm hex head screws
• 4 x M4 standard nuts

Here are the technical drawings showing the dimensions:
