FJ Cruiser Handle mount for RAM MOUNT

NOTE: NOT RECOMMEND FOR FJ CRUISER WITH A-PILLAR AIR BAG, WHERE IT COULD CAUSE INJURY IN CASE OF ACCIDENT. The is FJ…
22
59
1
1362
updated March 20, 2023

Description

PDF

NOTE: NOT RECOMMEND FOR FJ CRUISER WITH A-PILLAR AIR BAG, WHERE IT COULD CAUSE INJURY IN CASE OF ACCIDENT.

The is FJ Cruiser Handle bracket for RAM Mount (RAM-B-238U)

  • You could use the OEM handle bolt no additional bolt is required.

This Idea inspired by: https://www.thingiverse.com/thing:4246610

To complete the setup you could print:

1x RAM Mount Diamond Ball Base (RAM-B-238U) : Attached File

1x RAM Mount Double Socket (RAM-B-201U) : https://www.thingiverse.com/thing:267879

1x 1" to 17mm Ball Socket: Attached File

-Update 12/12/2021 : Reduce the overhang for more rigidity.

Print Settings

Printer Brand:

Ultimaker

Printer:

Ultimaker 2

Rafts:

Doesn't Matter

Supports:

Yes

Resolution:

0.2

Infill:

50-70

Filament: Generic ASA-ABS-PETG

Notes:

Increase the wall and roof layers to 2mm
Use heat resistance material

Category: Automotive
