This setup fixed all the issues I was having with the printer. Thank you so much!

Nicolas Morales

@NicolasMorale_886887

Me gustaría que me contarán y me guiarán en la conexión del segundo ventilador de capa ya que no se dónde debo conectar

Scorpion_3D

@Scorpion_3D_183027

@NicolasMorale_886887 no se si habras encontrado solucion pero yo corte el cable que alimenta el ventilador y de ahi saque dos conexciones, puedes usar algun tipo de conector pequeño por si se romper algun ventilador sea mas facil cambiarlo

Andy Lo

@AndyLo

I made some changes and I adapted it to my Ender 3
Nice and fast to print

Faig Bagirov

@FaigBagirov_368710

Almost perfect version, thank you.
I made minor changes for my direct drive and 450c (large) heater block upgrades. I also added few shapes to the heatbreak duct to get rid of ziptie. If someone has same upgrades and want to use this awesome enclosure, let me know.

Roland Deschain

@RolandDeschain

This came out great! At first I wasn't sure if my mount was low enough (it's adjusted as low as it will go) but my prints are coming out great.

There were some minor differences from the instructions on my recently purchased Ender 3 V2 and some tweaks I made so here they are:

1) I drilled out a small chamfer/countersink for the two screws that attach the BLTouch to the bracket so they would sit flush (maybe this could be built-in to the model)

2) While attaching the mount to the carriage the left most screw needed to be M3 x 6mm to not hit the back.

3) Additionally the center most hole on the carriage was not tapped with threads so I used a M3 x 10mm and a nylock nut. (edited)

cdsmakestuff

@cdsmakestuff

@RolandDeschain Awesome! glad you like it... I have also been experimenting using two 12v blower fans instead of the 24v fans. It "overdrives" them a bit and there life expectancy is probably decreased, but if you need A LOT of cooling, it can make a difference.

Roland Deschain

@RolandDeschain

@cdsmakestuff finally got a chance to install this and love it! I updated my original post with a suggestion and some differences I ran into with my particular printer.
