TS100 adapter for soldering iron holder
Adapter for a standard cheap soldering iron holder to better fit the TS100
1
24
0
336
updated August 30, 2022
Description
PDFJust a simple adapter for a cheap solder iron holder I had. This replaces the plastic part of the holder. Two washers is added during the print that holds the TS100 iron securely.
Pause at layer 93 (18.60 mm) and 223 (45.60 mm) to add the washers. Printed with a brim.
Parameters in fusion360
| Name | Expression |
| washer_1_outer_diameter | 24 mm |
| washer_1_inner_diameter | 13.1 mm |
| washer_1_thickness | 2.6 mm |
| washer_2_outer_diameter | 25mm |
| washer_2_inner_diameter | 6.55 mm |
| washer_2_thickness | 1.5 mm |
