extruder-idler-mmu2s_cut08

An idler with a changed tip shape.
0
70
1
332
updated May 22, 2022

Description

PDF

In the previous part, a specific filament did not work well, so I changed the shape near the sensor.

The reason why the body through which the shaft bolt penetrates is made thicker is that a support must be added at the time of output, and in order to output beautifully, the thickness is added according to the tip shape.
