Laser beam aligner

When you have aligned your lasers beampath to perfection, you now need to be sure the beam is 100% vertical to make a straight cut through the material.

Here you have a simple tool to make this alignment.

-First make sure you hit the nozzle in the middle by adjusting your mirrors.

(for this I use a homemade gauge with some painters tape)

-Put a piece of painters tape under the cone.

-Place the cone directly under the nozzle and raise the table until the cone centers gently on the tip.

-Fire a short pulse.

-Now it's easy to see if the spot is in center using the aiming lines under the cone.

If not, you need to move the cutting head a little bit, and then try again until you hit dead center.

(Remember to check and adjust also at the nozzle every time you move the head)

-PEPSI-

Print Settings

Printer Brand:

Anycubic

Printer:

All-metal Mega

Rafts:

No

Supports:

No

Resolution:

0.2

Infill:

25%

Filament: Unknown PLA
