CR6-SE PTFE-Tube Spool Holder

A flat spool holder making use of the original spool holder arm using a PTFE tube (bowden tube) with 4 mm OD as a sliding surface for the filament spool. This is heavily inspired by the spool holder solutions for the line of Voron printers over at VoronDesign.

The PTFE tube can be inserted from one side and is then locked wen the holder is inserted in the holder arm and secured with the pin.

No testing to capacity limit was done, but normal 1 kg spools are held without any problems. There was also no topology optimization done to find the best and least amount of filament use due to restrictions of fusion 360.

Since both parts are in one fusion file the pin needs to be re-oriented in the slicer software of your choice.

Print Settings:

0.4 mm nozzle

0.2 mm layer height

0.4 mm extrusion width

5 Walls

5 Top

5 Bottom

40 % infill (gyroid)

printed without supports, but supports can help with clearance issues

Print Settings

Printer Brand:

Creality

Rafts:

No

Supports:

No

Resolution:

0.2

Infill:

40%

Filament:

Black
