Turnigy D2826 2200kV Motor Mounts

Motor mount for the Turnigy 2826, 2200kV motor.

Another little project off the smokey Anet A8!

Two versions; a 90 deg angle mount, good for front mounting. Also a 12 deg tilted mount, which is good for pusher mounting.

Also a raised open platform to get the motor higher up. I used the tilted mount and platform combination on the little Mugi Coreflute / Corro / Correx Flying Wing.

Recommend printing motor mounts with multi-hole (motor) part on the build plate. No need for supports; drill out the four mounting holes if they are a bit out of round.

For the raised platform lay it down as per the picture; so again no need for supports while printing.

Print Settings

Printer Brand:

Anet

Printer:

A8

Rafts:

No

Supports:

No

Resolution:

0.2mm

Infill:

100% (solid)

Filament: Any PLA Any

Notes:

Recommend printing with multi-hole (motor) part on the build plate. No need for supports; drill out the four mounting holes if you need to to make them round again.
