Mega_Zero_2.0_LJ18A3_8_ZBX mount

Mount for inductive ABL Mega Zero V2.0

Setup Hardware

Big thanks to

this guy

for solving my issues. For Mega Zero V2 you will need to use a 1K resistor between BLUE and BLACK wire to make it work. and a 6.8K for the V1 or other printers using 12V.

Klipper Config

[probe]

pin: ^!PC4

x_offset: 47

y_offset: 17

[bed_mesh]

speed: 150

horizontal_move_z: 8

mesh_min: 102, 35

mesh_max: 285, 225

probe_count: 5,5

[stepper_z]

step_pin: PB3

dir_pin: PB2

enable_pin: !PA5

microsteps: 16

rotation_distance: 8

endstop_pin: probe:z_virtual_endstop

position_min: -10

position_max: 250

Parts Used

Link to LJ18A3 Sensor.

Link to Anycubic Mega Zero V2.

Category: 3D Printer Parts
