Joying 10.1 screen mount for Fj cruiser

This extends the screen out to clear the dash and adds a 8° of tilt

Joying has made a lot of models and there is some variation on the bolt

pattern on the deck and the micro sd card slot location

recommendations:

Print a few layers on the deck mount with the bolt pattern lying flat on the bed and stop and use as templet for the bolt pattern

and remix as needed

Needed for assembly

Screen needs 8 M2.5x6mm

Deck needs 8 M2.5x8mm

------------------------------------------Update 7/17/20 fix list-------------------------------------------

-fixed hole location on screen mount

-added 2020 deck mount for newer radios with sd cards in lower left

-added 4 hole screen mount for e-z printing

Feel Free to upload remix's with model #'s for others

Print Settings

Printer Brand:

Prusa

Printer:

i3 MK3

Rafts:

No

Supports:

Yes

Resolution:

.2

Infill:

25

Filament: amazon Petg Black
