Stackable screw-top watch parts tray

I really liked the Screw Top Watch Movement Tray by ADWWOOD (https://www.thingiverse.com/thing:4965114), but I needed a few different things. If you have a project that is going to sit for a while (like when you order a part and wait for it to arrive), I'd like to have it sealed for security instead of just sitting loose under the standard dome tray. I redesigned everything from scratch. My design has a large bottom section to store the crystal, case, watch back, movement ring, etc. You can then screw on the middle section where you can put your movement parts. Then, you can screw on a lid. I also made a bottom section with dividers in case you just want more places to put parts. I then designed an additional middle section to safely and securely hold the dial, day and date wheels. Finally, you can just place the lid on upside down so it acts as a dust cover while you are working (or use a standard dome, which sits "OK" on the top).

UPDATE: As of 4-17-22, I updated new STL's. These new files have been edited for better clearance of the threads for an easier fit.

Print Settings

Printer Brand:

Creality

Printer:

Ender 3

Rafts:

No

Supports:

Yes

Resolution:

.20 but .12 is better

Infill:

25%

Filament: Hatchbox PLA White

Notes:

The outer rim doesn't look as nice at 0.20, and the threads work better at 0.12 0.12 will take a while to print, especially the middle part.

Parts Tray Middle: Middle section with space for movement and movement parts

Parts Tray 3-Middle: A middle section to safely house your dial, date and day rings. Space for other parts as well.

Parts Tray Bottom: A taller open area for case, back, etc.

Parts Tray D-Bottom: A copy of the middle section with space for movement and movement parts, but set up as a bottom part.

Ender 3V2

How I Designed This

Fusion 360
