Pin2DMD Data East mounting kit

This kit is for mounting a Pin2DMD EVO board to Data East pinball machine. Spacers are required as the LCD panels on…
0
13
0
238
updated April 30, 2022

Description

PDF

This kit is for mounting a Pin2DMD EVO board to Data East pinball machine. Spacers are required as the LCD panels on the EVO board push against the clear plastic window (at least in my case).

Print each board spacer (4 corner and 1 mid/edge section) and 5 of the cylindrical offsets. Print spacers with gaps facing up. There is only one install orientation.

Print Settings

Printer Brand:

Creality

Printer:

Ender 3

Rafts:

No

Supports:

No

Resolution:

0.3
