GeeeTech Prusa i3b - Front Switch Box Remix

This box is a remix of the very good Kafarn's things (https://www.thingiverse.com/thing:806826)

I have grouped Power switch and the 2 small switches (1 for fan and 1 for light in my idea) in the same box.

I have added a separator between high (110/220v) and low (12v) to avoid any contact.

Hope that will be useful for somebody.

Thank's to Kafarn.

Edit 2017 oct 19 : I was said that my first box (that is ok on my own machine) is too high for some I3 Pro B. I made a new version (v2) according to the size I was given. Then if you have 58mm to the top of the plate use v1, if you have 55mm, use v2 (see picture).

Print Settings

Printer Brand:

Prusa

Printer:

Prusa Clone

Rafts:

No

Supports:

Yes

Resolution:

0.2mm

Infill:

30%
