Ultimaker 2 - E3D hotend mount

This is my design of a mount for an E3D v6 hotend for an ultimaker.

the cooling fans is 2 40x10 mm blower fans bought from aliexpress

the fan brace nay not be needed.

(the extra holes is for a bed leveling sensor at some day)

Print Settings

Printer:

Ulti-Alu-Maker

Rafts:

No

Supports:

Doesn't Matter

Resolution:

0.1 mm

Infill:

60

Filament:

Notes:

orient files as needed
