Creality CR-10 Mini IR Sensor Mount
Simple mount for the mini ir z probe sensor board found here to be used with Auto Bed Leveling. Requires flashing the…
0
9
0
136
updated April 30, 2022
Description
PDFSimple mount for the mini ir z probe sensor board found here to be used with Auto Bed Leveling. Requires flashing the firmware.
Uses stock screw hole on left side after removing the fan housing and allows for height adjustment to get to just the right spot.
Connect VCC to 5V, GND to Z end stop ground pin and OUT to the other Z end stop pin. Enable FIX_MOUNTED_PROBE in marlin and then determine and set the Z Probe offsets.
