gt2 2mm 12mm wide idler 24t 11mm bearing ( 5x11x4)

Customized version of http://www.thingiverse.com/thing:16627 Created with Customizer!…
5
20
0
121
updated April 26, 2022

Description

PDF

Customized version of http://www.thingiverse.com/thing:16627

Created with Customizer! http://www.thingiverse.com/apps/customizer/run?thing_id=16627

Instructions

Using the following options:

profile = 12

teeth = 24

additional_tooth_depth = 0

m3_nut_flats = 0

idler_ht = 1.5

idler = 1

retainer_ht = 1.5

motor_shaft = 11

pulley_t_ht = 12

pulley_b_dia = 20

additional_tooth_width = 0.2

nut_shaft_distance = 1.2

pulley_b_ht = 0

m3_nut_hex = 0

m3_nut_depth = 0

retainer = 1

no_of_nuts = 1

nut_angle = 90

m3_dia = 0

Category: 3D Printer Parts
