TS100 Hip Flask Case

Design streams available here: https://www.youtube.com/watch?v=O_khw6cFQJs&list=PLaTs09sSqm36AyPFkkUPsmaGAmIIMUc5g&index=1

This is a TS100 case I designed because I wanted to carry the thing around, but all I had was the original packaging, and I didn't like everybody else's flip-top designs.

Will Hold:

1. 1x TS100
2. 4x TS100 tips

a. OR 2x TS100 tips and 1x USB-C to 5.5x2.5 adapter 3. 1x Sponge 4. 1x Wire iron stand 5. 1x 1.5mm hex key

Features

This has a pocket for the sponge and the iron stand (with tabs to keep it upright), and a pocket on the back for the hex key to tighten the tip retention screw and grounding screw. It is intended to work with the iron stand bent wire and sponge from the typical kit that everyone buys.

There is also a pocket to hold four tips, two of which have been widened to accomodate a USB-C to 5.5x2.5 DC barrel adapter, which I carry with me instead of a more conventional lithium battery or DC power supply since I already carry a rather large USB-C battery pack. Links to all that are available in the design stream playlist, and I'll add and update links to all that once I figure out how to get affiliate links working.

There's also my logo on the back, because I'm vain and I think it looks cool. :^)

If you'd like a version without a logo, feel free to email or DM me and I can send you an STL, or you can modify the SLDPRT/STEP to remove it yourself. All I ask is that if you do this, please don't repost it elsewhere. I don't really expect to make much money if any at all from this, since I'd much rather tutor or make educational videos to help people do CAD better, but this sort of this makes great advertising.

If you like this design...

Please post your finished prints so I can evaluate any issues with the overhangs above the access holes to the tip pockets. I was able to print them just fine, though I am running a Petsfang V2 and have pretty well tuned temperatures for short bridges of that sort.

Print Settings

Printer Brand:

Creality

Printer:

CR-10S

Rafts:

No

Supports:

No

Resolution:

0.2mm

Filament:

Overture PLA

Space Gray How I Designed This ===================

See design streams: https://www.youtube.com/watch?v=O_khw6cFQJs&list=PLaTs09sSqm36AyPFkkUPsmaGAmIIMUc5g&index=1

I made a mistake on the first stream and my audio was muted for the first hour or so, but besides that I try to describe what I'm doing and my thought process to make it easy for people inexperienced with or actively learning computer-aided design to learn how to design better components.
