spare part D12 for Tamiya CW-01 Lunchbox Midnight pumpkin

This is a spare part. I include 2 versions. V1 matches the original part closely but broke sometimes. V2 is a bit more sturdy.

Print with 100% infill and lying on the side so that the filament lines are going perpendicular to the disk to maximise strength in that direction.

After print drill out the hole for brass fitting / screw with a 4mm drill bit and the one where the damper screw goes in with a 2.5mm bit.

Print Settings

Printer Brand:

Anycubic

Printer:

All-metal Mega

Rafts:

No

Supports:

Yes

Resolution:

0.16

Infill:

100%

Filament: no specific PLA Black
