DELTA planer blade setting tool

Blade adjustment tool
2
42
0
421
updated April 25, 2022

Description

PDF

A remix of BrokenPoet's excellent blade setting tool for Delta thickness planers. The original tools are no longer available from Delta and are often not sold with the planers because they are not stored with the machine.

This remix includes a debossed description of what it is and a couple of recesses for 12mm X 3mm magnets.

Following BrokenPoet's lead, I am including both the STL and the Fusion 360 file.
