OV5647 IR-Cut Camera Shell and Mount

This is a simple mount for the OV5647 style IR-Cut Cameras that mounts to the Articulating Mount by Sneaks.
42
365
3
1409
updated April 24, 2022

Description

PDF

This is a simple mount for the OV5647 style IR-Cut Cameras that mounts to the Articulating Mount by Sneaks.

It has cutouts for 9mm heatsinks, as seen being used for the Raspberry Pis.

Simply mount the Camera by pushing it into the Top Case and screwing the Bottom Case on with 4x M3x10 hex bolts, as commonly found on the Prusa MK3S.

For any modifications, I have provided the CAD files. You can also optionally contact me if you're not able to do the modifications yourself, I'll be happy to help ^^
