Bearing Filament Guide

Filament Guide using two bearings to have minimum friction.

The bearing on top allows the pulley to turn in the direction the filament is being pulled.

Required Hardware:

• 2x M3x25mm + nut
• 1x M4x20mm + nut
• 1x M5x8mm + t-nut (for mounting to 2020 aluminium profile)
• 1x 624 bearing (4x13x5mm)
• 1x 608 bearing

Print Settings

Rafts:

No

Supports:

No

Resolution:

0.2

Infill:

30%

Filament: EFORINK PLA Red

Notes:

Make sure to orient the parts right.
Especially top and spacers.
