Dial indicator holder for EVA hotend or fan 40x40 (Update V2)

Dial indication holder for EVA hotend of fan 40x40 to accuracy level bed
1h 0m
1× print file
0.20 mm
0.40 mm
5.00 g
Creality Ender 5
3
36
0
274
updated April 3, 2022

Description

PDF

Hi,
I designed this to verify the accuracy level of the bed, this bracket is designed for an EVA hotend but if you have a 40x40 fan you should use this to level the bed.
Printing:
I printed it in this orientation:


-infill 40%
- walls 3

I printed this on my modified ender 5 plus

Changelog

V2 - Modifying so that it does not obstruct the fan
