Runcam 3 Mount for Vortex 250 Pro

I designed this mount to attach a Runcam 3 that was wearing this TPU sleeve https://www.thingiverse.com/thing:2306842

The mount uses one of the protective lens jut outs to lock the front into place. Then a velcro strap can be wrapped around the underside of the mount, through the legs.

The mount sets the camera at a 20 degree angle.

You can slip the camera in and out of the mount without removing the VTX antenna.

I printed this in PLA at a 60% infill for strength. It has survived a half dozen crashes without issue.

Print Settings

Printer Brand:

Wanhao

Printer:

Wanhao Duplicator i3 V2

Rafts:

No

Supports:

Yes

Resolution:

.2

Infill:

60%

Notes:

Print in normal orientation. Foot flat on the build plate.
