Arcade Joystick mechanism

This is the base and mechanism for a 3D printed arcade joystick. This is meant to be added into your design (123d source files included) and is not a stand alone item.

Be careful with your tolerances, If the keeper and effector aren't snug on the shaft of the bolt, the joystick will not spring back to center after you move it. The keeper should be able to move up and down the shaft freely, but have minimal wobble

Print Settings

Printer:

i3 prusa style

Rafts:

No

Supports:

No

Resolution:

.2

Infill:

20%, make it strong

Post-Printing

Parts

You'll need an M8 bolt for the joystick shaft, 4 standard uSwitches (http://www.amazon.com/Micro-Limit-Switch-Roller-Action/dp/B00H8TIEHW/ref=sr_1_1?s=industrial&ie=UTF8&qid=1459951417&sr=1-1&keywords=micro+switch) and a spring roughly 12.5mm OD, 11mm ID ( I got mine at home depot for 75 cents).
