Low Profile LED Strip Diffuser (2020 Extrusion)

This is a slim, low clearance LED strip holder for RGB/neopixel strips WITH the clear Silicone coating. I found a few diffusers that only fit the PCB strips, but were too small for the ribbons with the waterproof Silicone.

Works well. Easy to snap into place.

Print Settings

Printer:

FLSUN i3 2017 Customized

Rafts:

No

Supports:

No

Resolution:

.3

Infill:

0%

Filament:

Overature PETG

Clear

Notes:

Import the model, and scale your Z to how long you need.
For Cura, use "Spiralize Outer Contour."

Other slicers use "Vase Mode"

Remove top/bottom.

Designed and printed for 0.5mm nozzle. Should work just fine with 0.4mm nozzle. 0.6mm might be a bit too snug, but you might want to test a small section depending on your printer's tolerances.

Category: 3D Printer Accessories

Inspired by DryFry's model 4139774, I designed my own profile to allow thicker LED Strips.
