Magnetic 1/4" Router Bit Holder

What is it?

It's a very simple router bit holder designed to hold [x23] 1/4" router bits in place. Design also has [x4] pockets that can store accessories such as collets or bit sharpeners. Note: ⌀5mm to ⌀6mm magnets can be glued into each hole to provide additional holding support. Top row has increased spacing to accommodate larger / wider router bits.

Dimensions.

• Holder Overall: 200mm x 140mm x 30mm

• Pocket Size: 26mm x 73mm x 10mm

• Bit Holes: ⌀6.7mm (with slight taper to lock bits)

• Magnets Used: ⌀5.5mm x 1.8mm

How to print?

No supports, 0.3mm layer height (or whatever)
