100mm Corner Pocket Router Jig
Basic clamp-able router jig to cut a 100mm corner pocket in material.
11
10
0
176
updated
January 22, 2026
Description
PDFWhat is it?
It's a basic router jig built to be clamped to the corner of material used to route out a 100mm pocket for recessed parts or to hide joints.
Dimensions.
Router Jig Dimensions: 146mm x 148mm x 80mm
Pocket Hole Dimensions: 100mm x 100mm x 33mm
How to print?
PETG (advised), 4+ wall count perimeter for strength.
No supports, 0.3mm layer height (or whatever)
Tags
Model origin
The author marked this model as their own original creation.
