xBloom Side Phone Holder (L or R)

This is my version of a xBloom side phone holder using the gap to slide a frame on which you screw the holder. The entire system can be used on the right or left side, the frame is symmetrical and reversible.

You will need 2 x M3 bolt 8mm long. I made conical holes for easy insert. Do not apply excessive force to tighten on the final rotations.

The holder bottom hook is made to accept phone with cases up to approx. 10mm thick

Material

• 2 x M3 bolt - 8mm long

Printing Info

• Wall loops: Minimum 3

• Infill: Gyroid minimum 15%

• Top & Bottom shell layers : 5 (For the holder to have 0 infill layers and the frame to flex less on the corners)

• Filament: Matte black NX2 PLA from Extrudr
