Diffusion-Based Self-Watering Planter

Description

The planter consists of an inner terracotta pot encased in a 3D-printed outer shell. The space between the pot and the shell acts as a water reservoir, allowing moisture to slowly diffuse through the porous terracotta into the soil.

This self-watering system is ideal for plants that require consistently moist soil and is not suitable for plants that need dry periods between watering.

Examples of Suitable Plants

• Herbs: mint, basil, parsley

• Ferns: Boston fern, maidenhair fern, bird’s nest fern

• Tropical houseplants: calathea, peace lily, monstera, philodendron

• Vegetables: lettuce, spinach, chard

• Flowering plants: begonias, impatiens, hydrangeas

3D-Printed Parts

• Simple:
  110 mm diameter pot with a clean, minimalistic design and a top thread for mounting the cover plate.

• Revolve_var:
  110 mm diameter pot with an edged, knurled exterior and a top thread for mounting the cover plate.

• Revolve_var_withRefillBore:
  110 mm diameter pot with an edged, knurled exterior and a top thread for mounting the cover plate.
  With an 20 mm bore in order to refill the pot without open the top lid.

• Cover Plate (Cover_plate_part1 & Cover_plate_part2):
  Screws into the pot’s top thread. The split design allows installation after planting. Inner opening approximately 80 mm in diameter.
  Print with 97-98% scale for easier fit.

Hardware

• Terracotta or clay pot:
  Height: 100 mm
  Diameter: 110 mm

• 2K Turbocoll or similar

• Optional: Polyurethane coating for additional water proofing

Amazon Link: https://www.amazon.de/-/en/KOTARBAU-Terracotta-Flower-Diameter-Gardens/dp/B0B6BWRPPY?th=1
