Kossel Mini carriage for IGUS DryLin TWE-04-12

A Kossel Mini carriage adapter suitable for linear bearings from IGUS, type TWE-04-12. The horns have been moved to center position and mountings for GT2 open loop belts have been added. The part is a remix from jcrocholl's original Kossel Mini carriage in OpenScad.

I have used IGUS DryLin® carriages due to their low noise and lubricant/maintenance free glide pads. Also they are easier to acquire here in Germany than the ones proposed in the original BOM.

What you need

Please note: All links to Amazon (amzn.to), AliExpress (s.click.aliexpress.com) or marked with * are affiliate links, through which I receive a small commission. Perhaps you would like to support my work by making a purchase.

Parts used (BOM)

• 2x M3 allen head screws, length depending on your rods

• IGUS DryLin linear rails
  https://www.igus.de/product/drylin_TW_04

Tools used

• Screwdriver or allen-key suitable for your M3-screws
  https://amzn.to/45a8DPQ

Suggested print settings

• Rafts: No

• Supports: No

• Resolution: 0.2mm layer thickness

• Infill: 30% or higher

Instructions

• Slice model and print three carriage adapters.

• Use M3 allen head screws to mount adapters on carriages.

• Insert one end of the corresponding GT2 open loop belt into the outer notch with about 2cm of extra length.

• Bend over the exceeding belt and insert it into the inner notch.

• Continue with the other end of the belt accordingly.

• Use M3 allen head screws to mount spherical bearings.

• Enjoy a smooth ride 😉
