Mads Vortex Shade

The Mads Vortex Shade is a precision-engineered spiral lampshade designed specifically for vase-mode printing.
Its continuous vortex geometry forms a seamless single-wall surface, producing a clean, fluid twist with excellent light diffusion.
It prints exceptionally well in PETG (the images show a similar shade printed in transparent smoke-grey PETG), and also works with lightly translucent materials if a softer glow is preferred.

A 1.8 mm recessed base accommodates E14 or E27 fixtures.
A 1.2 mm bottom thickness is recommended for reliability.
All four sizes — S, M, L, and XL — preserve identical proportions and curvature, scaling consistently across different printer classes.

Dimensions (outer size)

Base diameter: 81.4 mm

• S: 142 × 142 × 130 mm
• M: 163 × 163 × 149 mm
• L: 214 × 214 × 195 mm
• XL: 244 × 244 × 223 mm

Recommended Print Settings

• Required: Vase Mode / Spiralize Outer Contour
• Layer height: ≤ 50% of nozzle diameter
  (e.g., 0.20 mm for 0.4 mm nozzle, 0.25 mm for 0.5 mm nozzle)
• Nozzle: 0.4 mm or larger
• Extrusion width: ~200% of nozzle diameter for the outer wall
• Bottom layers: up to 1.8 mm (1.2 mm recommended)
• Top layers: none
• Infill: 0%
• Speed: moderate for the cleanest surface finish

Material: PETG (transparent, tinted, or lightly translucent).
Photos show the model printed in transparent smoke-grey PETG.

Optional — Mild Perlin Fuzzy Skin (OrcaSlicer)

• Point distance: 0.4 mm
• Strength: 0.2 mm
• Feature size: 3 mm
• Octaves: 5
• Persistence: 0.75

Adds a subtle, even micro-texture that softens reflections and enhances the shade’s optical depth.

Included Files

Each size is supplied in two versions:

• E14 (28 mm opening)
• E27 (40 mm opening)

A total of 8 high-resolution STL files, ranging from 400–750 MB.
These models intentionally contain 8.5–15 million triangles for uncompromising surface smoothness.
Large-mesh warnings in slicers are expected and do not indicate an issue.

Customization

Custom variations are available on request, including:

• alternate opening diameters for specific fixtures
• proportional resizing beyond S/M/L/XL

Please contact me before purchasing if you require a customized version.
Approved custom variants will be added to the collection for all existing buyers.

Photos show similar PETG prints to demonstrate surface and light quality. The screenshot shows all included model sizes. A full print of the size L shade will be added once new smoke-grey PETG arrives.
