AKM to 1913 & buffer tube adapter. With or without a tang.

These AK adapters are made for AKM (with or without tang) to a mil-spec AR buffer tube or 1913 picatinny rail.

Materials -----------------

Reinforced versions take three to four  M4x20 button head bolts to prevent layer separation for weaker filaments. No threaded inserts needed.

Print Details -------------

For reinforced versions, print parallel to the print bed. If you're printing an un-reinforced version, angle the print with the receiver end in the air. Print at 100% infill, I've already added lightening holes to decrease the overall weight.

Install --------------------

For reinforced versions, thread in bolts quickly, preferably with a drill or electric screwdriver to prevent the bolt from getting stuck.

You do need to drill your own mounting holes because there are too many patterns of receiver that relocate the mounting holes.

Fitment------------------

As with everything made for AKs, hand-fitting my be necessary. If its too loose you can always clip a thin cylinder into the wall of the adapter, then interference fit the adapter into your receiver with a mallet like a zenitco handguard.
