Elegoo Mars Resin-Filter Holder

I thought Jimmi's holder's design was perfect, but he had built it around this aluminium profil. I wanted to use some cheap scrap steel tubes, which I happen to have lying around instead.

My design now uses a steelpipe with outer diameter 22,5 mm (other diameters are possible). Other than that, only some M6 screws, washers and nuts are needed.

I will publish the SolidWorks Files also. So you can tweak it easily.

I have included the SolidWorks Assembly-File. Unfortunatly this filetype is not supported. So you have to rename this to  “Filterhalterung.SLDASM”

You should print this with 0,2 mm Layer Height and 5 Perimeters. Infill 15% is sufficient.

--------------

changes 2022-03-06  00:17: replaced the Vat-Holder

changes 2022-03-15: Base plate is a little bit flimsy. So I have to make some minor changes. But I ran out of filament. I have to wait till the weekend to reprint the parts. After that I will update and publish the files including STL/3MF.

changes 2022-03-19: reuploaded new versions of CAD-Files. Foto of ready assembled thing will follow
