SV08 BTT Manta M8P Cooling Plate 120

I've designed a mount for an 120x15mm fan to cool the Manta M8P in my SV08.

It mounts on the 4 original mountig holes of the board so it shouldn't be limited to the Sv08.

You will need to have raised feet on the SV08 because the Heatsinks of the M8Ps drivers already are flush with the bottom of the printer.

📦 Bill of Materia (BOM):

For Cooling Shield:

4x M3x40 screws (to mount the shield through the board)

1x 120x15mm fan (I use an ARCTIC P12 Slim PWM https://www.amazon.de/dp/B08QDKGCCW?ref=ppx_yo2ov_dt_b_fed_asin_title&th=1 since it is  low noise and work great on PWM and the M8P supports 12V fans)

4x M3 heat set inserts (3mm height, 5mm OD)

4x M3x18 screws (to mount the fan)

I've used the files from Nadir to design a mount for an 120x15mm fan to cool the Manta M8P in my SV08.
