Langmuir Titan Press Brake Tools

Here are Fusion and STEP files of some of the common Titan Pressbrake tools. Specifically the:

• 4-Way Die Holder
• Acute 16.5mm 30° Die
• Standard 4-Way Die
• Extreme Gooseneck 85° Punch
• Gooseneck 88° Punch
• Heavy Duty 35° Punch

Please note I scrabbled these together from the parts on hand and the (limited) information available from Langmuir. I can't guarantee their accuracy. I made them to help me design a cabinet to hold them. But… I'd be careful making any critical decisions based on these files! Ha ha. Including the original files so you can modify to match your tools, if you discover they are different or you want to add detail. Feedback welcome.
