ESP32-C3 S3 Supermini WLED Case
Description
PDFESP32-C3 Supermini WLED Case
This is a remix of @dm1x_1486268’s ESP32-C3 Supermini WLED Case with several modifications for better usability and cooling.
🔧 Changes in this remix:
ESP32 rotated and USB-C connector hole added for easier access.
Added side and bottom vents for improved airflow.
Two additional cable routing holes for power wires.
Extra hole for a JST XH 2.54 female 3-pin connector (can be glued in place for secure fit).
Added two screw holes in the bottom for mounting with M3 bolts.
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
ESP32 rotated and USB-C connector hole added for easier access.
Added side and bottom vents for improved airflow.
Two additional cable routing holes for power wires.
Extra hole for a JST XH 2.54 female 3-pin connector (can be glued in place for secure fit).
Added two screw holes in the bottom for mounting with M3 bolts.
