ESP32 Cheap Yellow Display PC Mount

Mount a 2.8" ESP32-2432S028 cheap yellow display in your PC. Use it to display images, videos, or system stats.

HOW TO BUILD

• Put the cheap yellow display into the casing. Use 4 X M3*10 screws to close it.
• Mount the cheap yellow display into your PC using the L-bracket. Use M3 screws and nuts.
• You can directly screw the casing onto the bracket using long M3 screws, the smartphone magnet mount is optional.

ESP32 MJPEG VIDEO PLAYER

• Flash “MPLAYER.zip” onto the ESP32. Original credits : https://www.youtube.com/watch?v=jYcxUgxz9ks
• Format micro SD card as FAT32, copy videos in "MJPEG” folder.
• For cards more than 32GB, you need to use command line (windows) - format X: /fs:fat32 /q
• Use FFMPEG to convert video to MJPEG format - ffmpeg -i INPUT.mp4 -vcodec mjpeg -an -q:v 5 -filter:v fps=20 -vf "scale=240:320,setdar=3/4" OUTPUT.mjpeg

OTHER ESP32 PROJECTS

• CYD System Monitor - https://github.com/iamlite/CYD-System-Monitor/
• Animated GIF Player - https://github.com/vinc-ee/ESP32-GIFPlayer
• Photo Album - https://www.instructables.com/Make-a-Digital-Photo-Album-by-ESP32/

PARTS LIST

These are my affiliate links, they do not cost more. But I will make a small commission for every sale, that will help to offset some costs of my future projects.

• ESP32-2432S028 (2.8 inch) - https://s.click.aliexpress.com/e/_c4DT47kT
• Fake SD cards are rampant on AE! Only buy from official brand stores (Lexar, Orico) - https://s.click.aliexpress.com/e/_c3dOZMST | https://s.click.aliexpress.com/e/_c311hYp1
• SD Card Reader - https://s.click.aliexpress.com/e/_c3BNOQyB
• 9 Pin To USBC - https://s.click.aliexpress.com/e/_c45fu3jh
• Angled USB Adapter - https://s.click.aliexpress.com/e/_c3VIETz1
• Smartphone Magnet Holder - https://s.click.aliexpress.com/e/_c3A4FjRl
• M3 Screws & Nuts - https://s.click.aliexpress.com/e/_c3WBJpj9

PRINT SETTINGS

• Material - PLA or PETG
• Layer Height - 0.2mm to 0.28mm
• Supports - Can be printed without supports.

Changed back plate to pan head, added PC mounting bracket.
