Stream Deck Mount for Razer Blackwidow TE Chroma v2

Overview Updated: The design has been adjusted to tilt back the stream deck slightly for more stability, especially…
8
81
0
1400
updated February 28, 2022

Description

PDF

Overview

Updated: The design has been adjusted to tilt back the stream deck slightly for more stability, especially when using the keyboard feet. I've also increased the height of the "tab" on the support to better grip the keyboard.

I wanted a tidy Stream Deck mount for my beloved Razer Blackwidow keyboard that wouldn't move about. This will work with other Razer keyboards that have the same profile and maybe a few others.

The model is available on TinkerCAD: https://www.tinkercad.com/things/bIz7shAX9cE-dazzling-bruticus and is in 2 pieces to allow modification for other keyboards and printing with minimal supports. There are 3 files:

*Combined - Stream Deck Razer Blackwidow TE Chroma v2 Mount.stl is a combined model that you can split yourself *Support_-_Stream_Deck_Razer_Blackwidow_TE_Chroma_v2_Mount.stl is the part which clips to the keyboard and supports the frame *Frame_-_Stream_Deck_Razer_Blackwidow_TE_Chroma_v2_Mount.stl is the part which holds the Stream Deck

Printing Instructions

I printed this in PLA, other materials should work. ABS may shrink a bit, YMMV. Print theframe "face down" with ~5mm brim. You may wish to "paint" supports on the overhangs of the truss supports. Print thesupport without supports (chuckle) with the largest flat surface down (facing your print bed). Thesupport should not need a brim.

Assembly

You may need to trim, file or smooth the ends of the trusses on theframe to fit into thesupport slots. I applied a few drops of cyanoacrylate (CA) glue to the slots on thesupport and along the groove on the edge of theframe that joins to thesupport. Once dry, it will clip nicely above the function keys on your keyboard. The Stream Deck can be inserted sideways on an angle from the back of theframe.

Modification For Other Keyboards

You should be able to tweak thesupport to fit other keyboards. If you use TinkerCAD, ungroup thesupport and tweak the depth of the top or angle of the back as needed. Changing the angle of the back may change the angle of theframe. Acknowledgement for remixes and modifications is appreciated.

Print Settings

Printer Brand:

Prusa

Printer:

I3 MK3S

Rafts:

No

Supports:

No

Resolution:

.15mm

Infill:

15%

Filament: Hatchbox PLA Black

Category: 3D Printing

Tags



Model origin

The author marked this model as their own original creation. Imported from Thingiverse.
