SuperPINDA Probe Mount — Remix

Source: Remix of “Stealthburner super PINDA mount” by Sanchez12 — CC-BY 4.0.
This remix license: CC-BY 4.0 (attribution required).

Included files

STL (printable)

STEP (editable CAD)

Measured from this remix STL

Bounding box (W×D×H): 12.81 × 23.88 × 30.70 mm

Surface area: 1545.24 mm²

Volume: 1191.36 mm³

Probe: SuperPINDA (Ø ≈ 8 mm). Verify bore fit after print.
Hardware: 1× M3 hex nut (~5.5 mm AF), 1× M3 screw (length per clamp thickness).
Compatibility: Stealthburner form factor; Dragonburner unverified.
No firmware/config included.

Keeps M3 clamp format.

Uses captive M3 hex-nut pocket for clamping (no heat-set).

Adds vertical adjustment slot in the arm.

External envelope retained.
