Marble Kit V (Elevator set)

Warning: This project is in the testing phase and may undergo changes. Any feedback that helps the project move forward will be appreciated.

This project is an extension of the Marble Kit V project: https://www.printables.com/model/1357470-marble-kit-v

Information

The aim of this project is to create a closed marble run. As it is a modular project, I had to create a modular lifting system. With this chain lifting system, you can make it as high as you want.

The project is currently under development. The ultimate goal of the project is to attach a motor to the chain so that it is no longer manual.

Model parts

Chain

Pieces that allow the marbles to climb. It is recommended to print at 100% fill for greater durability.

Elevator base

Where the marbles enter the elevator.

Elevator top

Where the marbles come out of the elevator

Wheel

Wheel that allows the chains to move. Print 2

Axis

Connect the wheel to the lever. Print 2

Lever

Where the elevator is operated. Print 2

Assembly

Base

Place the wheel in the middle in the correct orientation, then insert the axle and finally attach the lever.

Top

Place the wheel in the middle in the correct orientation, then insert t

he axle and finally attach the lever.

Chain

Press each link onto the previous one. Then pass the chain through the lifter and join the two ends.
