Plates with rulers AND grooves to lock stuff

I need to place "very vertical" items on the plates, whith must be hold properly. The grooves and holders will help.
3
4
0
71
updated August 22, 2025

Description

PDF

Some stuff I have to put on the plates must be hold by something. The holder will help lock them into place.

You WILL need to print your own locking tool that will go into the holder, obviously, since your needs will probably be very different from mine. Teeth are 5 mm long, 2 mm  wide. Spacing between teeth is 10 mm.

Model origin

The author remixed this model.

Differences of the remix compared to the original

Added symatrical, circular grooves on the round plate, and orthogonal ones on the squarish plate. And build two holders, one for the round plate, one for the squarish one.

Color change at the fourth layer (grooves at 0.6 mm deep).
