GT3 RS shelf
Shelf inspired by Porsche GT3 RS design. Modeled in Autodesk Fusion.
9
58
0
207
updated
October 2, 2025
Description
PDF- The size is just right for a print bed of about 220x220 mm (I have Genius Artillery printer).
- I recommend adding modifiers with denser infill in the slicer to strengthen the mounting points.
The main body uses 20% infill, while the modifiers use 30% infill, or more. - You can use some MDF board 600x200 or 800x200mm for shelf itself. (e.g. IKEA BURHULT, TRANHULT… ). Feel free to use any different you want.
- GT3RS logo sign is white-sprayed and glued to the side wings.
- Mounting holes are Ø=6mm (wall) and Ø=4.5mm (shelf).
- Countersunk head screws needed:
- 4 bigger wood screws into wall - 5x60-80mm
- 6 screws to mount both side wings - 4-4.5x30mm
- 4 screws to mount shelf to the consoles - 4-4.5x20mm
- TIP: Use black screws for a better final look. I didn’t have any black ones in the proper size.
- NOTICE: print is long due to its size, please be patient. Every part took several hours.
