Sensor-Bracklet TSL2561 for SensorBox V2

A Bracket to snap into the sidewall of the SensorBox V2 that holds a light-sensor module TSP2561.

I connected the sensor module via I2C, using the port for the ENS160 on the print v1.1. The sensor controls the brightness of the display. The code to do this will follow.

There exist a version to mount the module left or right in the housing of the SensorBox. The module is positioned to “look” through one of the triangle openings of the housing.

My module snaps into the Bracket and the Bracket snaps into the housing. If it do not fit, you can use a drop of super-glue or modify the tolerances. To modify the tolerances you can edit my FreeCAD-file of the Bracket that I put into this project.

The Bracket was printed on my SonicVyper from Eryone PLA black, a 0,4mm nozzle and with 0,2mm LH.

I printed it with the front-face down so there are no unprintable overhangs.
