CAT6A RJ45 Keystone Patch Panel Conversion

A 3d model to convert a terminating CAT5 patch panel to CAT6A keystones
2
5
1
142
updated July 31, 2025

Description

PDF

I needed to convert my old patch panel that uses crimp termanials to RJ45 keystones (yes I hate working with termination, and this is just easier. And it uses the origional mounting screws.

Please note - the edge bumps on the keystones need to be trimmed with flush cutters to allow them to mount closer together with minimal gaps

These are printed in PETG at 0.36mm layer height
No supports needed
