These are CAD-files of an enclosure for the TONEX One Pedal, including the Waveshare ESP-S3 1.69 Touch controller in landscape mode. It has been designed to be as compact as possible.
In addition to the three printed parts a double-angled USB-C silicone flat cable with a minimum length of 14cm, a 6.3mm TRS jack and a 5.6/2.1mm jack for 5V power supply is needed.
Please be advised that the base plate of the TONEX ONE pedal needs to be removed and replaced with this housing. This may affect the warranty of the pedal.
I would like to sincerely thank the programmers of the TONEX ONE CONTROLLER (https://github.com/Builty/TonexOneController) as well as IK Multimedia for the excellent TONEX ONE pedal!
The author marked this model as their own original creation.
