LED strip rail support for 3030 extrusion
Supports for mounting a 17x7mm led strip rail on a 3030 aluminum extrusion
0
1
0
17
updated July 4, 2025
Description
PDFPrint on the side, without supports.
Each support requires a 3030 M6 T-slot nut and an M6x12 screw.
In my experience it is sufficient to have 2 supports for 50cm of rail.
Suitable for 17x17mm aluminum LED strip rails/guides, e.g.: https://www.amazon.de/dp/B07549CLDV?ref=ppx_yo2ov_dt_b_fed_asin_title
